| 22 | 6750967 | CAP-BREATHER |
| 23 | 103328 | LOCKWASHER |
| 24 | 187396 | COUPLING |
| 25 | 144218 | BUSHING |
| 26 | 433142 | BOLT |
| 27 | 179860 | BOLT |
| КРЕПЛЕНИЕ ТРАНСМИССИИ | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 271621 | BOLT |
| 2 | 9012026 | SPACER(0.25 IN) |
| 3 | 9012544 | MOUNTING |
| 4 | 9355771 | NUT |
| 5 | 9136532 | NIPPLE |
| 6 | 271568 | BOLT |
| 7 | 2337379 | CLAMP |
| 8 | 9141843 | HOSE |
| 9 | 271562 | BOLT |
| 10 | 103331 | LOCKWASHER |
| 11 | 9003673 | WASHER |
| 12 | 9003685 | BUSHING |
| 13 | 108580 | LOCKWASHER |
| 14 | 179839 | BOLT |
| 15 | 223453 | BOLT |
| 16 | 103332 | LOCKWASHER |
| 17 | 9195340 | CAP-FILLER |
| 18 | 9268885 | LOCKWASHER |
| 19 | 9066677 | RING |
| 20 | 15257170 | ADAPTOR |
| РАЗБОРКА ТРАНСМИССИИ | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6777070 | FLANGE-INPUT |
| 2 | 15258084 | FLANGE-TRAMS OUTPUT |
| 3 | 6772182 | NUT |
| 4 | 6776246 | PLATE-RETAINER |
| БЛОК УПРАВЛЕНИЯ | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6777974 | GASKET |
| 2 | 6835409 | PLATE-OIL TRANSFER |
| 3 | 6830003 | WASHER |
| 4 | 23018739 | BOLT |
| 5 | 9409030 | BOLT |
| 6 | 6839632 | GASKET |
| 7 | 23012877 | PLATE-SEPARATOR |
| 8 | 6839633 | GASKET |
| 9 | 103339 | WASHER |
| 10 | 9427847 | BOLT |
| 11 | 9433579 | BOLT |
| 12 | 29536510 | HARNESS ASSY |
| 13 | 12052410 | TERMINAL |
| 14 | 12059716 | CONNECTOR-BODY |
| 15 | 454813 | BOLT |
| 16 | 23019734 | SOLENOID-12V |
| 17 | 23046848 | SEAL |
| 18 | 29524652 | SCREW |
| 19 | 6779833 | GASKET |
| 20 | 6833223 | SPRING-OUTER |
| 21 | 6830243 | SPRING-INNER |
| 22 | 6880187 | BALL-CHECK |
| 23 | 29525044 | PLUG ASSY |
| 24 | 6759964 | SPRING |
| 25 | 6769825 | SPRING |
| 26 | 6778593 | SPRING |
| 27 | 6830014 | SPRING |
| 28 | 6830240 | SPRING |
| 29 | 6830237 | SPRING |
| 30 | 6779835 | GASKET |
| 31 | 103339 | WASHER |
| 32 | 9418964 | BOLT |
| 33 | 186284 | BOLT |
| 34 | 179851 | BOLT |
| 35 | 433114 | BOLT |
| 36 | 6838821 | GASKET |
| 37 | 23045751 | COVER ＆ PLATE |
| 38 | 6838904 | GASKET |
| 39 | 23019734 | SOLENOID-12V |
| 40 | 23046848 | SEAL |
| 41 | 6779852 | GASKET |
| 42 | 12059716 | CONNECTOR-BODY |
| 43 | 12052410 | TERMINAL |
| 44 | 6835526 | GASKET |
| 45 | 186290 | BOLT |
| УПРАВЛЕНИЕ ПЕРЕКЛЮЧЕНИЕМ | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15231519 | RELAY |
| 2 | 15247614 | FUSE-5AMP |
| 3 | 15247612 | FUSE-10AMP |
| 4 | 109084 | NUT |
| 5 | 179820 | NUT |
| 6 | 103320 | LOCKWASHER |
| 7 | 103340 | WASHER |
| 8 | 9251501 | BRACKET |
| 9 | 179838 | BOLT |
| 10 | 108580 | LOCK WASHER |
| 11 | 102635 | NUT |
| 12 | 179795 | BOLT |
| 13 | 103339 | WASHER |
| 14 | 103319 | LOCKWASHER |
| ОТБОР МОЩНОСТИ-ТРАНСМИССИЯ | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9413386 | RING |
| 2 | 907559 | BEARING |
| 3 | 9413409 | RING |
| 4 | 9182510 | SHAFT |
| 5 | 9182507 | GEAR |
| 6 | 219305 | PLUG-PIPE |
| 7 | 9148275 | O RING |
| 8 | 9182511 | SHAFT |
| 9 | 907451 | BEARING |
| 10 | 9182508 | GEAR |
| 11 | 102578 | SCREW |
| 12 | 444625 | PLUG(0.38 IN) |
| 13 | 9182350 | HOUSING |
| 14 | 907561 | BEARING |
| 15 | 9003659 | SHIM(0.008 IN) |
| 16 | 9003530 | SHIM(0.020 IN) |
| 17 | 9003658 | SHIM(0.003 IN) |
| 18 | 179860 | BOLT |
| 19 | 103328 | LOCKWASHER |
| 20 | 444613 | PLUG |
| 21 | 15252873 | ADAPTOR |
| 22 | 15255329 | HOSE ASSY |
| 23 | 15252983 | ELBOW |
| ФИЛЬТР | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 29503834 | FILTER ASSY |
| 2 | 15270496 | ELEMENT |
| 3 | 23018958 | SEAL |
| 4 | 23018846 | SWITCH |
